Hi everyone! Let me present you my latest design, a direct remote extruder (second version) which uses the dual drive bondtech style gear-set, as I like to call it "Remote BMG".
This version of the design allows attaching of a Nema 8 or a round Nema 14 stepper, transforming it to a mini lightweight direct extruder.
The design is still under "constructions" so Beta testers are welcome!
This is an improved version of my first Remote Direct extruder design:https://www.thingiverse.com/thing:4012273
Check out my new direct extruder based on planetary gearbox here:https://www.youtube.com/watch?v=FZiO0bkMALA
Link to the Fusion360 design files:
Nema 8:https://a360.co/2yWMNmZ
Remote Bowden flexi-shaft:https://a360.co/2UXEgHL
Round Nema 14:https://a360.co/2UNXyQU
WormGears 10:1https://a360.co/2K3Wou9
WormGears 20:1https://a360.co/2Rvq5sd
